DuraCirc

A Alfa Laval DuraCirc® revolucionária é a primeira bomba de pistão circunferencial que oferece o equilíbrio perfeito entre durabilidade, confiabilidade, alta eficiência e sanitariedade máxima. Combinada com uma grande variedade de vazões e pressões com características de manutenção simples, a DuraCirc mantém os processos ativos e em funcionamento.

Chega de compromissos: a melhor opção da categoria com performance absoluta, sanitariedade máxima e serviços mais simples – tudo na mesma bomba

  • Otimizada para alta eficiência volumétrica, garantindo uma seleção de bomba econômica e alta qualidade do produto
  • Projeto higiênico compatível com padrões globais, inclusive EHEDG e 3-A
  • Operação confiável e de longo prazo graças à construção durável, robusta, resistente e totalmente em aço inoxidável
  • Fácil de consertar e manter com peças e sobressalentes totalmente intercambiáveis
  • Alta flexibilidade no processo e custos de capital reduzidos por causa da grande variedade dos tamanhos de modelos, das vazões e das pressões

A performance da bomba, o desenho higiênico e a facilidade de manutenção são essenciais para os processos higiênicos. Ainda assim, os fabricantes dos setores de laticínios, alimentos, bebidas, confeitaria e higiene e limpeza muitas vezes devem sacrificar um elemento essencial para conseguir outro. Não mais. A CPP (Circumferential Piston Pump, Bomba de pistão circunferencial) Alfa Laval DuraCirc® oferece tudo – alta eficiência volumétrica, conformidade com EHEDG e 3-A, além de serviços rápidos e fáceis.

Tendo em vista uma seleção de bomba econômica e com amplo escopo de aplicação, a linha consiste em 13 modelos, com capacidade para vazões de até 150 m3/h (660 gpm) e pressões de 40 bar (580 psi).

Simplifique os serviços em termos de complexidade e tempo com características amigáveis ao usuário, inclusive um selo mecânico único verdadeiramente de carregamento frontal e autoajustável, além do uso de um único óleo lubrificante de vida útil prolongada e calços externos.


Engineered for durability, reliability and efficiency to extend the boundaries of your performance



Supreme Performance

Designed with close pump head clearances, the DuraCirc® CPP pump maximizes volumetric efficiency and process yield. Thirteen models offer a wide performance envelope with a flow rate capability up to 150 m3/hr (660 gpm) and operating pressures up to 40 bar (580 psi). This makes optimal pump sizing and selection easy, thereby reducing capital costs and increasing process flexibility.



Based on a robust, reliable design, DuraCirc® features include:

  • Advanced port and pump-head geometry, providing a very low NPSHr characteristic. This significantly reduces cavitation risk and maintains pump and media integrity whilst increasing process flexibility in challenging applications
  • Long-life, heavy-duty bearings, supporting rigid shafts located in a solid stainless steel gearcase, which reduce shaft movement and allow close pump-head clearances. This minimizes pump-head contact and ensures process uptime
  • A modular seal design, which makes seal conversion easy without requiring re-machining or additional flush housings, should the process application change
  • An optional retrofit port, the DuraCirc® Uni-Fit, enabling easy, direct replacement of existing circumferential piston pumps from both Alfa Laval and other brands, without requiring pipework modification in existing process systems



Safely meets industry hygienic demands, assuring  the integrity of your processes and
the quality of your products



Superior Hygiene

The all-stainless-steel DuraCirc® is certified to meet global standards for hygienic design, including EHEDG and 3-A. In contrast to many other circumferential piston pump brands, the DuraCirc® provides both excellent cleanability and high volumetric efficiency.



Features that reduce the risk of contamination include:

  • Profiled, product-wetted elastomers that are FDA-compliant and have a defined compression, thereby eliminating crevices and dead zones
  • A robust gearcase with optimally positioned heavy-duty bearings that support large diameter shafts, which minimize pump-head contact, thereby reducing the risk of media contamination
  • An all-stainless steel construction suitable for hygienic washdown, ensuring a cleaner environment
  • Long-lasting, FDA-compliant gearbox lubricant
  • Optimized seal design with faces fully immersed in the pumped media for higher cleaning efficiency


Innovative design features make maintenance faster and easier, increasing uptime in your operations



Simpler Service

Increase process uptime and make service faster and easier with innovative DuraCirc® design features. Perform standard maintence procedures quickly and simply, without requiring gearbox disassembly, component re-work, or complex pump re-build procedures. Features include:



  • A truly front-loading, self-setting, single mechanical seal for fast, in-situ seal replacement, without having to remove the pump from the process line
  • Quick, easy replacement of rotors or rotor case in the unlikely event replacement is required
  • Easy-to-access, external shimming outside the rotorcase instead of inside the gearbox
  • Fully interchangeable spare parts
  • Long-life bearings, offering tens of thousands of hours of operation
  • A single, long-life, FDA-approved gearbox lubricant with an extended 3,000-hour change interval

.

DuraCirc® product brochure

Discover how the DuraCirc® offers Supreme Performance, Superior Hygiene and Simpler Service.

.

Easy condition monitoring for hygienic pumps

The Alfa Laval CM monitors the operating condition of rotating equipment, such as pumps

Como funciona

.

The DuraCirc® construction features two rotors, housed within a pumping chamber, known as a rotorcase, with each rotor located on a shaft held rigidly within a gearcase. The two rotors are timed via timing gears in the gearcase, which along with shimming, ensures no rotor or rotor case contact. Rotor/shaft drive is typicially provided via geared electric motor.

Due to the close internal running clearance within the pumping chamber, the rotation of the rotors continuously generates a partial vacuum in the suction port of the pump as the rotors unmesh. This results in a localized pressure drop, which allows fluid to enter the pump. The fluid is then transported around the channel by the rotor wings; the pressure generated as the rotor wings re-mesh forces the fluid out of the discharge port of the pump.

DuraCirc Pump Exploded Cut away 640x360
